BendPak HD-9XL 9,000-lb. Capacity Four-Post Lift – Extended-Length Vehicle Lift with Standard Width, Multi-Level Safety Locks

Overview

The BendPak HD-9XL is a professional-grade, high-capacity four-post lift engineered for automotive shops and home enthusiasts who need to service or store vehicles with longer wheelbases. While maintaining the footprint of a standard parking space, the HD-9XL features runways that are roughly 24 inches longer than the standard HD-9 model, making it the ideal solution for full-sized trucks, extended SUVs, and classic long-wheelbase luxury cars. Powered by a maintenance-free electric-hydraulic system, this lift is designed to maximize vertical space, allowing you to stack two vehicles in a single bay or perform under-chassis maintenance with a generous 75 inches of overhead clearance.

Safety and structural integrity are the hallmarks of BendPak’s engineering. The HD-9XL is constructed with heavy-duty aircraft-quality cables and features a redundant safety system with 14 mechanical locking positions spaced every 4 inches. Unlike entry-level lifts, it utilizes specialized dual-hub cable sheaves to reduce friction and extend the lifespan of the lifting components. With its high-traction non-skid runways and a versatile "no-bolt" freestanding design, the BendPak HD-9XL is a high-efficiency powerhouse built to provide a lifetime of professional-grade vehicle storage and service.

Top Performance Features

• Extended 182-Inch Runways: Specifically designed to accommodate long-wheelbase vehicles that standard lifts cannot safely support.

• 9,000-lb. Lifting Capacity: A robust, over-engineered frame capable of hoisting everything from compact cars to heavy-duty pickups and SUVs.

• Dual-Hub Cable Sheaves: Industrial-grade pulleys that decrease stress on the 3/8-inch aircraft cables, ensuring smoother operation and superior longevity.

• 14 Multi-Level Locking Positions: Allows the operator to lock the lift at varied heights for comfortable standing-height service or precise vehicle stacking.

• Maintenance-Free Electric-Hydraulic Power: An integrated 220V power unit that provides quiet, consistent lifting with a simple push-button interface.

• Pneumatic Safety Release: Features a centralized push-button release that disengages all four locks simultaneously for a smooth, controlled descent.

• Internal "Anti-Sway" Slider Blocks: Housed within each column to guide the runways and prevent lateral movement during the lifting process.

• Integrated Rail Kit: The runways include a built-in rail system to support optional accessories like rolling bridge jacks, drip trays, and jack platforms.

Core Specifications

• Model Number: HD-9XL (SKU: 5175859)

• Lifting Capacity: 9,000 lbs (4,082 kg)

• Maximum Lifting Height: 75 Inches (1,905 mm)

• Overall Length: 224.5 Inches (5,702 mm)

• Overall Width: 110.25 Inches (2,800 mm)

• Width Between Columns: 100.25 Inches (2,546 mm)

• Lifting Time: ~50 Seconds

• Motor: 220 VAC / 60 Hz / 1 Ph

• Locking Spacing: Every 4 Inches

The Definitive Choice for Long-Wheelbase Storage and Service

The BendPak HD-9XL Four-Post Lift is the ultimate workhorse for those who view garage space as a premium asset. By merging an extended-length runway design with the industry-leading safety of dual-hub sheaves and 14 independent locking positions, BendPak has created a lift that excels in both versatility and peace of mind. It is a rugged, highly intelligent, and exceptionally durable system built to provide professional-grade results and a lifetime of service for your home collection or commercial shop.
